Mechanical Characteristics

Body / cab OT-58 brass (ON) – AISI-316L stainless steel (XX) marine grade copper free aluminium (on project request only)
Finishes Full nickel plating treatment (brass material only)
Rubber rings EPDM rubber 50-60 shore hardness (standard supply) Silicon rubber 60 shore hardness (on demand only)
O-ring Silicon rubber – 60 shore hardness
Skid washer Nylon 6.0

Application
For unarmoured cables only
Single compression type suitable for indoor and outdoor use
Single compression – on cable (inner sealing)

On Request Accessories
Locknuts, Gaskets, PVC Shrouds, Earthing Tags, Sealing (See DL-NW-PTD-ET bulletin)

PNA Metric Nickel Plated Brass PNA Metric Nickel Plated Brass – NPT

PNA#00MON   M16                       PNA#00NON    M16
PNA#01MON   M20                       PNA#01NON    M20
PNA#02MON   M25                       PNA#02NON    M25
PNA#03MON   M32                       PNA#03NON    M32
PNA#04MON   M40                       PNA#04NON    M40
PNA#05MON   M50                       PNA#05NON    M50
PNA#06MON   M63                       PNA#06NON    M63
PNA#07MON   M75                       PNA#07NON    M75
PNA#08MON   M90                       PNA#08NON    M90
PNA#09MON   M100                    PNA#09NON    M100

PNA Metric Stainless Steel        PNA Metric Stainless Steel – NPT

PNA#00MXX     M16                       PNA#00NXX     M16
PNA#01MXX     M20                       PNA#01NXX     M20
PNA#02MXX     M25                       PNA#02NXX     M25
PNA#03MXX     M32                       PNA#03NXX     M32
PNA#04MXX     M40                       PNA#04NXX     M40
PNA#05MXX     M50                       PNA#05NXX     M50
PNA#06MXX     M63                       PNA#06NXX     M63
PNA#07MXX     M75                       PNA#07NXX     M75
PNA#08MXX     M90                       PNA#08NXX     M90
PNA#09MXX     M100                    PNA#09NXX     M100
